1. Specification:
*Turntable diameter: 1500mm;
*Loading weight: 2000kg (Max)
*Turntable speed: 0-9 circle/Min
*Film carriage speed: 0-5M/Min
*Power/Voltage: 0.7KW, 220V;
*Machine size: 1900*1600*2100mm
2. Feature:
(A) Adopting programmable control (frequency converter),
(B) Reliable in performance, convenient in operation;
(C) Lapping type and times can be designed on customers' requirements,
(D) Equipped with a photoelectric detector,
(E) Automatically testing the goods height and controlling the travel limit,
(F) Rotary table can reset automatically to ensure correct and out position of
the tray.
(G) Convenient in film roll replacement,
(H) LLDPE film with external diameter?280mm,width?500mm& paper core
76 mm can be used.
(I) Custom-made specification is available,
(J) Providing a complete set of packing system of conveying line.
